Crimping Machines

精密プレス

Dual-end Crimp / Single-end Crimp to Crimp and Insertion

Fully Automatic Crimping Machines

JN07SD-IS-C

    Order production

    Dual-end crimp to crimp and Insertion machine equipped with multicolor wire selector

    • Features :
    • Insertion unit of proven and dependable “JACK” installed on side 2 makes it possible to process min. 40mm-length harness.
    • Set production for wires with different colors or cut lengths
    • A model for single-end soldering to crimping and insertion (JN07SD-IS-H) also available in our assortment
    Applications For Consumer Appliances, Wire Insertion Machine
    Wire Size AWG #26~ #22
